Summary
| Description |
English: Installed on an engine, this booster uses the engine’s exhaust gases to drive an air compressor to increase the pressure of the air going into the engine through the carburetor or fuel injection system to boost power at higher altitude. |
| Date | |
| Source | Pilot's Handbook of Aeronautical Knowledge, page 7-13 |
| Author | Federal Aviation Administration |
Licensing
|
This image or file is a work of a Federal Aviation Administration employee, taken or made as part of that person's official duties. As a work of the U.S. federal government, the image is in the public domain in the United States.
|
 |
