Summary
| Description | A demonstration of truck weight distribution, illustrating a practical application of the Federal Bridge Gross Weight Formula. |
| Date | |
| Source | SVG version of Figure 1 in http://ops.fhwa.dot.gov/freight/publications/brdg_frm_wghts/index.htm. The brochure is available at http://purl.access.gpo.gov/GPO/LPS76061. |
| Author | U.S. Department of Transportation/Federal Highway Administration. All images on the DoT site are in the public domain unless noted.[1] |
| Other versions | Image:Bridge formula 2.gif (GIF version) |
Licensing
|
This image is a work of a United States Department of Transportation employee, taken or made as part of that person's official duties. As a work of the U.S. federal government, the image is in the public domain.
|
|
